The Nissan Patrol Safari, commonly known as the VTC in the UAE and GCC, is one of the region's most popular vehicles for turbocharging. Its 4.8-litre TB48 inline-six engine has become a favourite among enthusiasts looking for more power while retaining the character of the original Patrol.
At Subzero Motorsport in Dubai, we offer two complete Nissan Patrol TB48 turbo packages: Stage 1, targeting 400–450 HP, and Stage 2, targeting 500–550 HP.
Both packages use the Garrett GBC37-900 turbocharger, but the supporting components are different. Stage 1 offers a more straightforward conversion, while Stage 2 includes additional fuel delivery, standalone engine management, internal engine upgrades and more extensive transmission modifications.
Both are installed and tuned at Subzero Motorsport, with manual and automatic configurations available.
Nissan Patrol TB48 Stage 1 vs Stage 2: What's the Difference?
The biggest difference between Stage 1 and Stage 2 is not the turbocharger. Both packages use the same Garrett GBC37-900 and TiAL 60 mm external wastegate.
They also share a ceramic-coated 304 stainless-steel turbo manifold, ceramic-coated 3.5-inch downpipe, powder-coated 3-inch intercooler, intercooler piping and a 304 stainless-steel 3.5-inch quiet-style full exhaust.
The main differences are the fuel system, engine management, internal engine components and transmission upgrades.
Stage 1 — 400–450 HP
Stage 1 targets approximately 300–350 wheel horsepower. It retains the factory ECU, fuel injectors, head gasket and oil pump gears, with a DeatschWerks DW300 fuel pump and upgraded hardwire power supply.
Stage 2 — 500–550 HP
Stage 2 targets approximately 400–450 wheel horsepower. It adds Injector Dynamics ID1050-XDS injectors, a boost-activated Walbro 525 secondary fuel pump, MaxxECU Track Gen 2, Greddy 2.0 mm head gasket and SZM billet oil pump gears.
Both stages include custom dyno calibration by Mohammad Al Jabri (MRJ), with transmission upgrades appropriate to the selected manual or automatic configuration.
These horsepower figures are approximate engine and wheel horsepower targets, not guaranteed dyno results. Actual output depends on engine condition, fuel quality, boost pressure and calibration.
Stage 1: Nissan Patrol TB48 Turbo Package — 400–450 HP
Stage 1 is our complete turbo conversion for Nissan Patrol Safari owners targeting approximately 400–450 engine HP, or 300–350 WHP.
It offers a significant increase in performance without the standalone engine management and internal engine modifications included in Stage 2.
The package includes the Garrett turbo system, upgraded fuel pump, full exhaust and custom ECU calibration. Automatic models also receive the appropriate transmission upgrade.
Garrett GBC37-900 Turbo System
The Stage 1 turbo system includes a Garrett GBC37-900 turbocharger, paired with a TiAL 60 mm external wastegate.
The exhaust side uses a ceramic-coated 304 stainless-steel turbo manifold and ceramic-coated 3.5-inch downpipe.
Charge-air cooling is handled by a powder-coated 3-inch intercooler with 3-inch intercooler piping. The installation also includes engine bay covers and powder-coated finishing.
The Garrett GBC37-900 provides the airflow capacity required for the Stage 1 power target, while the TiAL external wastegate regulates exhaust flow through the turbocharger to control boost pressure.
The ceramic-coated manifold and downpipe are built to handle the elevated exhaust temperatures associated with turbocharged operation.
Stage 1 Fuel System — DW300 with Hardwire
Stage 1 retains the factory TB48 fuel injectors and uses a DeatschWerks DW300 fuel pump with an upgraded hardwire power supply.
The DW300 replaces the original fuel pump, while the hardwire upgrade provides a dedicated electrical supply to support pump operation under increased engine load.
Unlike Stage 2, this configuration does not use larger fuel injectors or an additional boost-activated pump.
3.5-Inch Stainless-Steel Quiet-Style Exhaust
Stage 1 includes a 304 stainless-steel, 3.5-inch full exhaust system in a quiet-style configuration.
The system provides additional exhaust flow while maintaining a more controlled exhaust note for regular road use.
The full exhaust is included in the complete Stage 1 conversion.
Stage 1 Complete Package Prices
Stage 1 Manual — AED 34,500
The complete manual package targets 400–450 engine HP and includes the Garrett turbo system, DW300 fuel pump with hardwire, full 3.5-inch quiet-style exhaust, installation and custom dyno tuning by MRJ.
The factory manual clutch configuration is retained, subject to the condition of the existing components.
Stage 1 Automatic — AED 45,300
The automatic package includes the same engine and turbo system, along with the required automatic transmission upgrade and dedicated transmission cooling.
View Nissan Patrol Safari TB48 Stage 1 Turbo Package
Stage 2: Nissan Patrol TB48 Turbo Package — 500–550 HP
Stage 2 takes the TB48 further, targeting 500–550 engine HP, or approximately 400–450 WHP.
The turbocharger remains the Garrett GBC37-900, but the supporting configuration is more comprehensive.
Compared with Stage 1, Stage 2 adds larger Injector Dynamics fuel injectors, an additional fuel pump, standalone MaxxECU management, internal engine upgrades, additional monitoring sensors and upgraded transmission components.
Garrett Turbo System and Full 3.5-Inch Exhaust
Stage 2 uses the same Garrett GBC37-900 turbocharger and TiAL 60 mm external wastegate as Stage 1.
The turbocharger is paired with a ceramic-coated 304 stainless-steel manifold, ceramic-coated 3.5-inch downpipe, powder-coated 3-inch intercooler and matching intercooler piping.
A 304 stainless-steel, 3.5-inch quiet-style full exhaust is included.
Both packages use the same turbocharger model. The difference lies in the supporting hardware and engine management required for their respective horsepower targets.
Greddy 2.0 mm Head Gasket and SZM Billet Oil Pump Gears
Stage 2 includes two internal engine modifications not found in Stage 1.
Greddy 2.0 mm Head Gasket
The factory head gasket is replaced with a Greddy 2.0 mm gasket as part of the higher-boost engine configuration.
Correct installation and surface preparation remain essential to achieving proper cylinder sealing.
SZM Billet Oil Pump Gears
The original oil pump gears are replaced with SZM billet gears, selected for their additional mechanical strength under demanding engine operating conditions.
Both modifications and their installation are included in the complete Stage 2 package.
Stage 2 Fuel System — ID1050-XDS Injectors and Walbro 525
Fuel delivery is one of the main differences between the two stages.
Stage 1 uses factory injectors and a single DW300 pump. Stage 2 moves to Injector Dynamics ID1050-XDS injectors and a dual-pump fuel system.
Rather than replacing the factory fuel pump, Stage 2 retains it as the primary pump and adds a Walbro 525 secondary fuel pump that activates under boost.
The system also includes upgraded fuel pump wiring, a fuel pressure regulator and fuel pressure monitoring.
When the engine comes onto boost, the additional Walbro 525 supplies the extra fuel required at higher loads.
Together with the ID1050-XDS injectors, this arrangement provides the increased fuel delivery capacity required for the Stage 2 power target.
MaxxECU Track Gen 2 and Engine Monitoring
Stage 2 includes a MaxxECU Track Gen 2 standalone engine management system with single lambda and a custom engine wiring harness.
The system is paired with fuel pressure, oil pressure and intake-air temperature sensors, along with electronic boost control.
The standalone ECU provides greater control over fuel delivery, ignition timing and boost pressure.
Its additional sensor inputs allow important operating conditions to be monitored and, when correctly configured, incorporated into engine protection strategies.
Unlike Stage 1, which retains the factory ECU, Stage 2 uses standalone engine management as part of its complete specification.
Stage 2 Complete Package Prices
Stage 2 Manual — AED 66,489
The complete manual package targets 500–550 engine HP and includes the Garrett turbo system, ID1050-XDS injectors, Walbro 525 secondary fuel pump, MaxxECU Track Gen 2, Greddy head gasket, SZM billet oil pump gears, full 3.5-inch quiet-style exhaust, installation and custom dyno calibration by MRJ.
It also includes a McLeod RST twin-disc clutch.
Stage 2 Automatic — AED 71,139
The automatic package includes the same engine, turbo, fuel and electronics configuration, with a comprehensive automatic transmission overhaul replacing the manual clutch upgrade.
The automatic transmission work includes upgraded clutches, valve-body modifications, dedicated oil cooling and custom transmission cooler lines.
View Nissan Patrol Safari TB48 Stage 2 Turbo Package
Custom ECU Dyno Tuning by MRJ — Included in Both Stages
Both Stage 1 and Stage 2 turbo packages include custom ECU dyno tuning by Mohammad Al Jabri (MRJ) at Subzero Motorsport in Dubai.
Stage 1 retains the factory ECU, while Stage 2 uses the MaxxECU Track Gen 2 standalone engine management system. Despite the difference in ECU hardware, both packages require individual calibration.
Fuel delivery, ignition timing, boost pressure and other engine operating parameters are calibrated according to each vehicle's configuration, fuel quality and intended power target.
Every TB48 is assessed individually rather than relying on a generic calibration, particularly as engine condition can vary between vehicles.
Custom dyno tuning is included in the complete price of both packages.
Manual and Automatic Transmission Upgrades
Both Stage 1 and Stage 2 are available for manual and automatic Nissan Patrol Safari models, with transmission upgrades suited to each configuration.
Manual Transmission
Stage 1 retains the factory manual clutch configuration, subject to the condition of the existing components.
Stage 2 includes a McLeod RST twin-disc clutch to support the higher torque output.
Automatic Transmission
Both Stage 1 and Stage 2 receive the same automatic transmission upgrade package, which includes upgraded transmission clutches, valve-body rebuilding and modifications, a dedicated transmission oil cooler, custom cooler lines and new transmission fluid.
The complete transmission overhaul is designed to improve torque-handling capability and manage the additional heat generated during turbocharged operation.
Nissan Patrol TB48 Stage 1 vs Stage 2: Complete Package Prices
At Subzero Motorsport, we focus on complete TB48 turbo conversions rather than standalone turbocharger installations.
Our complete-package prices cover the specified supporting components, installation and custom dyno calibration.
Stage 1 Manual — AED 34,500
400–450 engine HP, approximately 300–350 WHP.
Stage 1 Automatic — AED 45,300
400–450 engine HP, approximately 300–350 WHP, including the automatic transmission upgrade and cooler.
Stage 2 Manual — AED 66,489
500–550 engine HP, approximately 400–450 WHP, including the McLeod RST twin-disc clutch.
Stage 2 Automatic — AED 71,139
500–550 engine HP, approximately 400–450 WHP, including the automatic transmission overhaul and dedicated cooling.
The difference in pricing reflects the additional fuel delivery capacity, standalone ECU, internal engine modifications, monitoring equipment and drivetrain upgrades included in Stage 2.
Prices are quoted in UAE dirhams (AED). Final quotations are subject to vehicle inspection, current pricing, VAT treatment and any additional work required outside the package specification.
Which Nissan Patrol TB48 Turbo Package Should You Choose?
The right package depends on your horsepower target, transmission type and intended use.
Stage 1 — 400–450 HP
Stage 1 suits owners looking for a substantial increase in performance with a simpler supporting configuration. It retains the factory injectors and ECU while including the Garrett turbo system, DW300 fuel pump, full exhaust and custom tuning.
Stage 2 — 500–550 HP
Stage 2 is intended for owners seeking higher output with more extensive supporting modifications. The MaxxECU Track Gen 2, ID1050-XDS injectors, boost-activated Walbro 525, Greddy head gasket, billet oil pump gears and upgraded drivetrain components make it a more involved conversion.
Importantly, Stage 2 does not use a larger turbocharger than Stage 1. Both use the Garrett GBC37-900.
The higher Stage 2 target is supported by the complete fuel, engine management and mechanical configuration rather than a change in turbocharger size.
Frequently Asked Questions
How much horsepower does a Nissan Patrol TB48 Stage 1 package produce?
Stage 1 targets 400–450 engine HP, approximately 300–350 WHP, depending on engine condition and final calibration.
How much horsepower does the TB48 Stage 2 package produce?
Stage 2 targets 500–550 engine HP, approximately 400–450 WHP, using the Garrett GBC37-900 with upgraded fuel delivery, standalone engine management and additional supporting modifications.
What is the main difference between Stage 1 and Stage 2?
Both use the same Garrett GBC37-900 turbocharger. Stage 2 adds ID1050-XDS injectors, a boost-activated Walbro 525 fuel pump, MaxxECU Track Gen 2, Greddy head gasket, billet oil pump gears, additional sensors and transmission upgrades.
How much does a complete Nissan Patrol TB48 turbo conversion cost in Dubai?
At Subzero Motorsport, Stage 1 costs AED 34,500 for manual and AED 45,300 for automatic models. Stage 2 costs AED 66,489 for manual and AED 71,139 for automatic models, subject to the current quotation.
Does Stage 1 include the fuel pump, exhaust and tuning?
Yes. The complete Stage 1 conversion includes a DW300 fuel pump with hardwire, 3.5-inch quiet-style exhaust and custom ECU dyno tuning by MRJ.
What ECU does Stage 2 use?
Stage 2 uses the MaxxECU Track Gen 2 standalone ECU, together with custom wiring, boost control and additional engine monitoring sensors.
Does Stage 2 replace the factory fuel pump?
No. The factory pump remains as the primary fuel pump, while an additional Walbro 525 activates under boost.
Do both TB48 turbo packages include dyno tuning?
Yes. Both stages include custom dyno calibration by Mohammad Al Jabri (MRJ). Stage 1 uses the factory ECU, while Stage 2 uses the MaxxECU Track Gen 2.
Can an automatic Nissan Patrol Safari be turbocharged?
Yes. Both stages are available for automatic models and include the appropriate transmission upgrades and cooling systems for their respective configurations.
Where can I get a Nissan Patrol Safari TB48 turbo installed in Dubai?
Subzero Motorsport in Al Quoz Industrial Area 3, Dubai, UAE, provides complete Nissan Patrol TB48 turbo conversions, including installation, engine upgrades, fuel-system work, transmission modifications and dyno calibration.
Nissan Patrol TB48 Turbo Packages at Subzero Motorsport Dubai
Whether you're targeting 400–450 HP with Stage 1 or 500–550 HP with Stage 2, choosing the correct configuration starts with your Patrol's condition and intended use.
Both packages use the Garrett GBC37-900 turbocharger, with supporting fuel, ECU, engine and drivetrain components selected for their respective performance targets.
At Subzero Motorsport, we handle the complete installation, supporting modifications, transmission work and custom calibration.
Explore our Stage 1 Nissan Patrol TB48 Turbo Package and Stage 2 Nissan Patrol TB48 Turbo Package, or contact our team in Dubai for a vehicle-specific quotation.
